tcpdump usage

一、获取适配器列表
$ tcpdump -D

二、监听适配器
使用 -i 或 –interface 参数监听适配器，适配器可以用序号或名字来表示，这些内容可以通过 -D 参数获取。macOS 下监听适配器的话，必须使用 root 权限。
　如果需要详细查看报内容，可以使用 -X 参数。

$ tcpdump -i en0 -X

三、监听适配器过滤
1、过滤主机
抓取所有经过 eth1，目的或源地址是 192.168.1.1 的网络数据
$ tcpdump -i en0 host 192.168.1.1

限定源地址
$ tcpdump -i eth1 src host 192.168.1.1

限定目标地址
$ tcpdump -i eth1 dst host 192.168.1.1

2、过滤端口
抓取所有经过 eth1，目的或源端口是 25 的网络数据
$ tcpdump -i eth1 port 25

限定源端口
$ tcpdump -i eth1 src port 25

限定目标端口
$ tcpdump -i eth1 dst port 25

3、过滤网段
$ tcpdump -i eth1 net 192.168

$ tcpdump -i eth1 src net 192.168

$ tcpdump -i eth1 dst net 192.168

4、协议过滤

$ tcpdump -i eth1 arp
$ tcpdump -i eth1 ip
$ tcpdump -i eth1 tcp
$ tcpdump -i eth1 udp
$ tcpdump -i eth1 icmp

5、使用表达式
与：&& 或 and
或：|| 或 or
非：! 或 not

$ tcpdump -i eth1 ‘((tcp) and (port 80) and ((dst host 192.168.1.254) or (dst host
192.168.1.200)))’

fabric 踩坑记

安装fabric2

坑1 ：由于轻信了一开始搜索到的fabric中文文档网页，该网页已经陈旧，正确安装方式为 fabric2

pip3 install fabric2

#or

pip install fabric2

pip3 install fabric2

#or

pip install fabric2

这里直接上我写好的fabric 脚本

#!/bin/python3
#coding=utf-8
from fabric2 import Connection
from invoke import run as local

def printResult(fabricResult):
    msg = "Ran {0.command!r} on {0.connection.host}, got stdout:\n{0.stdout}----------------------------------------------"
    print(msg.format(fabricResult))

def updateNewVersion(sshConn):
    sshConn.run("sh /root/shells/update_software.sh")
    #printResult(res)


if __name__ == "__main__":
    #compile new version
    local("rm -rf ./bin/shot", pty=True )
    local("CGO_ENABLED=0 GOOS=linux GOARCH=amd64 go build -o ./tar/shot ./src/shot", pty=True )
    local("shasum ./bin/tar",pty=True )
    #push to dev server
    sshConn  = Connection("testserver")
    sshConn.put("./tar/shot", "/root/temp/shot_newversion")
    updateNewVersion(sshConn)

#!/bin/python3

#coding=utf-8

from fabric2 import Connection

from invoke import run as local

def printResult(fabricResult):

msg = "Ran {0.command!r} on {0.connection.host}, got stdout:\n{0.stdout}----------------------------------------------"

print(msg.format(fabricResult))

def updateNewVersion(sshConn):

sshConn.run("sh /root/shells/update_software.sh")

#printResult(res)

if __name__ == "__main__":

#compile new version

local("rm -rf ./bin/shot", pty=True )

local("CGO_ENABLED=0 GOOS=linux GOARCH=amd64 go build -o ./tar/shot ./src/shot", pty=True )

local("shasum ./bin/tar",pty=True )

#push to dev server

sshConn = Connection("testserver")

sshConn.put("./tar/shot", "/root/temp/shot_newversion")

updateNewVersion(sshConn)

配置好本身ssh免密码登录

坑2：macos默认生成的id_rsa密钥格式可能不太正确，需要使用命令转换一下格式

ssh-keygen -p -m PEM -f ~/.ssh/id_rsa_testserver

1	ssh-keygen -p -m PEM -f ~/.ssh/id_rsa_testserver

#这是 ～/.ssh/config 文件中的配置
Host testserver
    HostName 192.168.1.220
    Port 10086
    User root
    IdentityFile ~/.ssh/id_rsa_testserver

#这是～/.ssh/config 文件中的配置

Host testserver

HostName 192.168.1.220

Port 10086

User root

IdentityFile ~/.ssh/id_rsa_testserver

use jquery ajax load image and put it to image tag src in base64 way

https://stackoverflow.com/questions/19124701/get-image-using-jquery-ajax-and-decode-it-to-base64/25371174

 $.ajax({
            url: "someurltoajpeg",
            type: "GET",
            headers: {
                "Authorization" : "Basic " +  btoa("user:pw")
            },
            xhrFields: {
                withCredentials: true
            },
            mimeType: "text/plain; charset=x-user-defined"
        }).done(function( data, textStatus, jqXHR ) {
        }).fail(function( jqXHR, textStatus, errorThrown ) {
            alert("fail: " + errorThrown);
        });

$.ajax({

url: "someurltoajpeg",

type: "GET",

headers: {

"Authorization" : "Basic " + btoa("user:pw")

xhrFields: {

withCredentials: true

mimeType: "text/plain; charset=x-user-defined"

}).done(function( data, textStatus, jqXHR ) {


}).fail(function( jqXHR, textStatus, errorThrown ) {

alert("fail: " + errorThrown);

});

function base64encode(str) {
        var CHARS = "ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/";
        var out = "", i = 0, len = str.length, c1, c2, c3;
        while (i < len) {
            c1 = str.charCodeAt(i++) & 0xff;
            if (i == len) {
                out += CHARS.charAt(c1 >> 2);
                out += CHARS.charAt((c1 & 0x3) << 4);
                out += "==";
                break;
            }
            c2 = str.charCodeAt(i++);
            if (i == len) {
                out += CHARS.charAt(c1 >> 2);
                out += CHARS.charAt(((c1 & 0x3)<< 4) | ((c2 & 0xF0) >> 4));
                out += CHARS.charAt((c2 & 0xF) << 2);
                out += "=";
                break;
            }
            c3 = str.charCodeAt(i++);
            out += CHARS.charAt(c1 >> 2);
            out += CHARS.charAt(((c1 & 0x3) << 4) | ((c2 & 0xF0) >> 4));
            out += CHARS.charAt(((c2 & 0xF) << 2) | ((c3 & 0xC0) >> 6));
            out += CHARS.charAt(c3 & 0x3F);
        }
        return out;
    }

function base64encode(str) {

var CHARS = "ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/";

var out = "", i = 0, len = str.length, c1, c2, c3;

while (i < len) {

c1 = str.charCodeAt(i++) & 0xff;

if (i == len) {

out += CHARS.charAt(c1 >> 2);

out += CHARS.charAt((c1 & 0x3) << 4);

out += "==";

break;

}

c2 = str.charCodeAt(i++);

if (i == len) {

out += CHARS.charAt(c1 >> 2);

out += CHARS.charAt(((c1 & 0x3)<< 4) | ((c2 & 0xF0) >> 4));

out += CHARS.charAt((c2 & 0xF) << 2);

out += "=";

break;

}

c3 = str.charCodeAt(i++);

out += CHARS.charAt(c1 >> 2);

out += CHARS.charAt(((c1 & 0x3) << 4) | ((c2 & 0xF0) >> 4));

out += CHARS.charAt(((c2 & 0xF) << 2) | ((c3 & 0xC0) >> 6));

out += CHARS.charAt(c3 & 0x3F);

}

return out;

}

win10 golang sqlite3

1. 安装mingw-w64
2. 设置mingw-w64的bin目录到path，使终端可以直接找到执行gcc命令
3. 使用go env 命令检查环境变量，看有没有 CGO_ENABLED=1
4. 编译测试

附上测试代码

package main
import (
  "github.com/jinzhu/gorm"
  _ "github.com/jinzhu/gorm/dialects/sqlite"
  "fmt"
)

type User struct {
  gorm.Model
  Name         string
  Email        string  `gorm:"type:varchar(100);"`
  Role         string  `gorm:"size:255"` // set field size to 255
  Num          int     `gorm:"type:int(10)"` // set num to auto incrementable
  Address      string  `gorm:"index:addr"` // create index with name `addr` for address
}

func main() {
  db, err := gorm.Open("sqlite3", "./gormtest.db")
    if err != nil {
        fmt.Print(err)
    }
  db.AutoMigrate(&User{})
  xiaoming := User{Name:"Xiao Ming", Email:"smallming@test.com", Role:"Group manager", Num:10010, Address:"xxx road 88 no"}
  errx := db.Create(&xiaoming).Error
  if errx != nil {
      fmt.Print(errx)
  }
  defer db.Close()
}

package main

import (

"github.com/jinzhu/gorm"

_ "github.com/jinzhu/gorm/dialects/sqlite"

"fmt"

)

type User struct {

gorm.Model

Name string

Email string `gorm:"type:varchar(100);"`

Role string `gorm:"size:255"` // set field size to 255

Num int `gorm:"type:int(10)"` // set num to auto incrementable

Address string `gorm:"index:addr"` // create index with name `addr` for address

}

func main() {

db, err := gorm.Open("sqlite3", "./gormtest.db")

if err != nil {

fmt.Print(err)

}

db.AutoMigrate(&User{})

xiaoming := User{Name:"Xiao Ming", Email:"smallming@test.com", Role:"Group manager", Num:10010, Address:"xxx road 88 no"}

errx := db.Create(&xiaoming).Error

if errx != nil {

fmt.Print(errx)

}

defer db.Close()

}

监控服务是否存活脚本

HEALTHY_URL = "http://127.0.0.1:8080/alive"


RESP=curl —-connect-timeout 3 -s ${HEALTHY_URL}

if [ "$RESP" == "ok"]; then echo "Server is running." exit 1 else echo "Serve was exit." exit 0 fi

docker 查看容器详情
docker inspect 容器ID
可是使用容器的IP地址访问容器相应端口来访问到容器上的关服务
